Glassfab Gia Square Inline Glass to Glass Hinge Standard Duty

$56.99$78.99

Glassfab Gia Square Inline Glass to Glass Hinge Standard Duty

Description

Our Glassfab Gia series shower hardware is the definition of style and functionality. These hinges features a 5-degree reversible pivot pin, ensuring stronger pressure on the jam or seal. You have the option of altering the closing position of the door 5 degrees inward by utilizing the opposite side of the pivot pin, which has been pre-machined. Elevate your bathroom with Glassfab’s Gia series for a premium blend of design and practicality.

Purchase all hardware within the Glassfab Series to ensure the same design and color.

Important Information:

Glass Sizes: 3/8” and 1/2″ (10mm and 12mm) thick tempered safety glass
Construction:
Solid Brass
Closing Type: Self-centering when within 15 degrees of closed position
Cutout Required: See Image

Maximum Door Capacities for          Two Hinges                Three Hinges
Maximum Door Weight:                       80lbs (36kg)                 120lbs (54kg)
Maximum Door Width:                         28” (71mm)                  32” (81mm)

Use of Gaskets:
For 3/8” (10mm) Glass: Use one thick gasket on each side.
For 1/2” (12mm) Glass: Use one thin gasket on each side.

Recommendations: For public safety, we recommend the use of only tempered safety glass. Power Tools are not to be used to secure faceplate screws.

Unit of Measure:  Each

HSI, HBI, HSIA AND HBIA DIMENSIONS
HSI, HBI, HSIA AND HBIA TEMPLATE
HSI, HBI, HSIA AND HBIA BREAKDOWN
